Rigid Flex PCBs is the combination of FPC and PCB. First of all, the electronic layout engineer design it according to their demand. After the CAM engineer processes and plans the relevant documents, then arrange the FPC production line to produce the required FPC and PCB production line to produce PCB. After the two flexible pcb boards and rigid pcb boards come out, according to the planning requirements of the electronic engineer, the FPC and PCB are seamlessly pressed together by the pressing machine. After a series of details, finally made a combination of Rigid Flexible PCB board.

The Rigid Flex PCBs has the characteristics of FPC and PCB at the same time, so it can be used in some products with special requirements, both flexible and rigid areas, to save the internal space of the product, reduce the volume of finished products, improve the product performance is of great help.

Rigid Flex PCBs is widely used in many industries, such as aerospace, military, medical equipment and so on. If you have any technical support on the design and production of Rigid Flex PCB boards, please feel free to contact us, we will try our best to help you out.

While improving the performance of the whole machine, electronic design also tries to reduce its size. HDI PCBs (High density Integration) technology enables end-product design to be miniaturized while meeting higher standards of electronic performance and efficiency. HDI PCBs is widely used in mobile phones, digital cameras, laptops, automotive electronics and other digital products, among which mobile phones are the most widely used. HDI PCBs is generally manufactured by Build-up method. The more times of build-up, the higher the technical grade of the board.

The HDI PCBs has many advantages, Rigao engineering team summarizes the following points. Firstly, the cost of PCB can be reduced, when the density of PCB increases to more than eight layers, the cost of manufacturing by HDI will be lower than that of the traditional complex pressing process. Secondly, facilitate the use of advanced construction technology, with better electrical performance and signal accuracy. Thirdly, HDI PCBs has good reliability, it can improve the thermal property and increase the design efficiency. The last, HDI PCB boards can improve RF interference (RFI), electromagnetic interference (EMI) and electrostatic discharge (ESD).

Rigao Electronics can provide customers with 4+N+4 structure HDI PCBs manufacturing services, as well as special laminates mixed press manufacturing services.

Special circuit boards with high electromagnetic frequency. Generally speaking, high frequency can be defined as frequency above 1GHz. Its physical performance, precision, technical parameters requirements are very high, often used in automotive collision prevention system, satellite system, radio system and other fields.

High frequency of electronic equipment is the development trend, especially in the wireless network, satellite communication development, information products to high speed and high frequency, and communication products to large capacity and fast wireless transmission of voice, video and data standardization, so the development of the new generation of products need high frequency substrate.

The laminate for High Frequency PCB produced by Rigao Electronics are all from brands like Roger, Arlon and Taconic. We are looking forward to your inquiry very much.

With the transformation of electronics industry to minisize, low power consumption and high performance, Rigao Electronics has earlier carried out technical layout in the field of high speed PCB and high-density PCB production, gradually overcome technical difficulties in terms of product signal integrity, power integrity, electromagnetic compatibility, clock system and bus system design, rule-driven layout and wiring, high-speed bus testing and verification, etc. And keep pace with the leading level of the industry.

We provide our customers with a one-stop solution for high speed PCB assembly manufacturing. Rigao Electronics focuses on the pain points of tight time, high requirements and high risks in the research and development stage of customers, and provides targeted solutions to help customers shorten the product marketing cycle and reduce research and development costs.

As a professional Electronic Contract Manufacturing supplier, we provide one-stop solutions from PCB Manufacturing and assembly services to enclosure build and final assembly services according to your requirements. Our enclosure build services include system-level assembly, product assembly, sub-level product assembly, firmware programming, function testing, packaging and labeling, product configuration.

Enclosure build also named system integration creates a completely finished assembly of products for customers. This process includes but not only the PCB fabrication, extending to electromechanical assemblies, such as components installation, electronic project box fabrication, and cables or wire harnesses. Enclosure build can refer to the PCB assembly (PCBA) in a cabinet full of wires. The project enclosure can be made of metal, plastic, and aluminum, and a fully integrated electro-mechanical system with pneumatics and electronics.

Rigao Electronics experienced in developing a customized turnkey manufacturing solution for highly complex and configurable Enclosure build assembly requirements, also we are flexible to accept turnkey, consignment, and hybrid material solutions per customer requirements.
